Dust Collector Filter Cartridges
Industrial Filter Cartridges, Matched to Your System
Novazure dust collector filter cartridges are supplied for industrial dust collection systems and replacement applications. Filter media options include polyester, nanofiber, and PTFE membrane media, with antistatic configurations available for specific operating requirements.
Filter cartridges can be specified according to your dust characteristics, filter dimensions, end cap design, sealing requirements, and installation configuration. Share your existing cartridge specifications, drawings, or samples to discuss suitable replacement filters and receive a quotation.
Industrial Filter Cartridge Media & Options
Polyester Filter Cartridges
Durable synthetic filter media for general industrial dust collection, suitable for selected dry dust applications and pulse-jet cleaning systems.
Nanofiber Filter Cartridges
Fine-fiber surface filtration media designed to support particle capture and dust release in suitable pulse-cleaned industrial filtration applications.
Antistatic Filter Cartridges
Filter media with conductive or static-dissipative features for applications requiring electrostatic charge control as part of a properly designed dust collection system.
PTFE Membrane Filter Cartridges
Membrane-laminated pleated filters designed to support surface filtration and dust cake release, with the base media selected for specific operating conditions.
Cellulose Filter Cartridges
Cellulose-based pleated filter media for selected dry dust collection applications, with suitability dependent on humidity, dust properties, and operating conditions.
Cellulose-Polyester Filter Cartridges
Blended cellulose and polyester filter media for selected industrial dust collection systems, combining different fiber properties according to the filtration requirements.
Special Configurations
Oval & Custom-Shaped Cartridges
Round, oval, and non-standard cartridge configurations can be evaluated for specific equipment designs and replacement requirements, subject to dimensional compatibility.
End Caps & Sealing Options
End cap designs, gasket materials, and mounting arrangements can be reviewed against existing cartridge specifications to support proper installation and sealing.
Filter cartridge media, surface treatment, dimensions, end cap design, and sealing configuration should be selected according to dust characteristics, temperature, moisture, cleaning method, and compatibility with the existing dust collection system.
How to Choose the Right Filter Cartridge
Filter Media & Dust Properties
Evaluate dust particle size, loading, abrasiveness, and adhesion when selecting polyester, nanofiber, PTFE membrane, or other suitable filter media.
Dimensions & Compatibility
Verify cartridge outer diameter, inner diameter, length, end cap design, and sealing arrangement to ensure compatibility with the existing dust collector.
Airflow & Cleaning System
Consider system airflow, available filtration area, operating pressure drop, and pulse-jet cleaning compatibility when evaluating filter cartridge performance.
Operating Conditions
Review operating temperature, humidity, chemical exposure, and electrostatic risks to determine suitable filter media and special requirements.
Filter Cartridge Dimensions & Customization
Filter Cartridge Specification Guide
Numbers 01–06 correspond to the specification checklist. Simplified illustration of a pleated cartridge with an open top and closed bottom; actual dimensions, end caps, and installation details require confirmation.
Frequently Asked Questions About Filter Cartridges
How do I choose the right filter cartridge media?
The appropriate filter cartridge media depends on dust particle characteristics, operating temperature, humidity, filtration requirements, and the existing filter cleaning system. Common options include polyester, cellulose, cellulose-polyester blends, nanofiber, and PTFE membrane media.
Share your dust properties, process conditions, and existing cartridge specifications so suitable filter media and surface treatment options can be reviewed before selection.
How do I measure a replacement dust collector filter cartridge?
The main dimensions are the outer diameter (OD), inner diameter (ID), and overall length (L). You should also identify the top and bottom end cap designs, gasket dimensions, and mounting configuration.
If you are unsure about the measurements, send us clear photos, an existing technical drawing, the original part number, or a sample. Final dimensions and installation compatibility should be confirmed before production.
Can you supply replacement filter cartridges for existing dust collectors?
Yes. Replacement filter cartridge requirements can be reviewed for existing industrial dust collection systems, including equipment supplied by other manufacturers.
Compatibility depends on cartridge dimensions, filter media, end cap construction, gasket design, mounting method, and operating conditions. Existing samples, photos, drawings, or original part numbers can help us evaluate suitable replacement options.
How long do industrial dust collector filter cartridges last?
Filter cartridge service life varies according to filter media, dust loading, operating temperature, moisture, cleaning frequency, and maintenance conditions. There is no single replacement interval suitable for every industrial dust collector.
Monitor differential pressure, dust collection performance, and the physical condition of the cartridges. Persistent high pressure drop after cleaning, damaged pleats, sealing problems, or reduced filtration performance may indicate that replacement is necessary.
Is there a minimum order quantity for custom filter cartridges?
Minimum order quantities may vary depending on the filter media, cartridge dimensions, end cap construction, customization requirements, and manufacturing arrangements.
Please provide your required quantity and specifications. We can review the order requirements and confirm the applicable minimum quantity together with our quotation.
What is the production and delivery lead time for filter cartridges?
Production lead time depends on the selected filter media, cartridge dimensions, end cap availability, order quantity, and any special customization requirements.
After reviewing your specifications and required quantity, we can provide an estimated production lead time with the quotation. Shipping time depends on the delivery destination and agreed transportation method.
Let's Discuss Your Dust Collection Needs
Whether you need a complete dust collection system, compact equipment, or replacement filters, share your requirements with us. We'll help you evaluate a suitable solution.
